SA312 TP304 Stainless Steel Welding Pipe OD 76.2×2.11mm

Brand Name:	KORER
Model Number:	OD: 6mm – 114.3mm, WT:0.3mm –4.5mm
MOQ:	1 Metric Tons Per Size
Price:	Negotiable
Payment Terms:	T/T L/C
Supply Ability:	10000 Metric Tons Per Year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001,PED and Manufacture License Of Pressure Tube

Item:

Stainless Steel Welding Pipe

Outside Diameter:

6mm-114.3mm

Wall Thickness:

0.3mm To 4.5mm

Length:

Max 20000mm

Standard:

SA249

Grade:

304 304L 316L 317L 904L

Welding Method:

TIG Or Laser Welding

Packaging Details:

Wooden Boxes With Angle Steel Frame Or Seaworthy Bundle

Supply Ability:

10000 Metric Tons Per Year

Highlight:

SA312 TP304 stainless steel pipe

welding pipe OD 76.2mm

stainless steel pipe with warranty

Product Description

SA312 TP304 Stainless Steel Welding Pipe OD 76.2*2.11mm

SA312 TP304 Stainless Steel Welding Pipe OD 76.2 *2.11mm - High-Quality Industrial Piping Solution

Product Introduction

The SA312 TP304 Stainless Steel Welding Pipe, with an outer diameter of 76.2 mm (3 inches) and a wall thickness of 2.11 mm, is a high-performance austenitic welded stainless steel pipe manufactured according to ASME SA312 / ASTM A312 standards. It is designed for demanding industrial applications where corrosion resistance, strength, and surface cleanliness are critical.

Applications

Chemical and petrochemical plants - for transporting corrosive fluids and gases
Food and beverage industry - for hygienic and non-contaminating processing lines
Power generation and boiler systems - for condensers and heat exchangers
Pharmaceutical and biotech systems - for sterile and clean piping environments
Water treatment and marine applications - for corrosion-resistant fluid transport

Advantages

Excellent corrosion and oxidation resistance, suitable for diverse environments
Bright annealed inner surface ensures smooth fluid flow and easy cleaning
High strength-to-weight ratio with consistent mechanical properties
Superior weldability and formability, compatible with various fabrication processes
Manufactured under ASME SA312 / ASTM A312, ensuring international standard compliance
Long service life and minimal maintenance, offering cost efficiency and reliability

Material Composition (TP304 Stainless Steel)

Element	Content (%)
Chromium (Cr)	18.0 - 20.0
Nickel (Ni)	8.0 - 12.0
Carbon (C)	≤ 0.08
Manganese (Mn)	≤ 2.0
Silicon (Si)	≤ 1.0
Phosphorus (P)	≤ 0.045
Sulfur (S)	≤ 0.03

Technical Specifications

Parameter	Value
Standard	ASME SA312 / ASTM A312
Material Grade	TP304
Outer Diameter	76.2 mm (3 inch)
Wall Thickness	2.11 mm
Length	Up to 12 meters
Surface Finish	Bright Annealed / Pickled / Polished
Type	Longitudinally Welded Stainless Steel Pipe
Certification	ISO 9001:2008, PED, Pressure Pipe License

Manufacturing Process

Raw Material Inspection → Slitting → Tube Forming → TIG/Plasma Welding → Bright Annealing → Straightening → Pickling or Polishing → Non-Destructive Testing (Eddy Current / Ultrasonic) → Dimensional Inspection → Marking → Packaging

FAQ

Q: What makes TP304 stainless steel suitable for industrial applications?

A: TP304 offers excellent corrosion resistance, heat resistance, and hygiene, making it ideal for chemical, food, and energy industries.

Q: Can the pipe be customized for specific projects?

A: Yes, dimensions, surface finish, and lengths can be customized to meet client requirements.

Q: What surface finishes are available?

A: Options include bright annealed, pickled, and mirror-polished finishes for different industrial needs.

SA312 TP304 stainless steel pipe 76.2mm stainless steel welded pipe ASTM A312 stainless steel tube TP304 welded stainless steel pipe ASME stainless steel tube bright annealed stainless steel pipe corrosion-resistant stainless steel pipe food-grade stainless steel tubing industrial stainless steel piping stainless steel pipe manufacturer China
